Team Brood “Crawler Brushed” Capacitor Bank
Original price was: $19.99.$11.99Current price is: $11.99.
- Protect Your Information, Shop with Safe Payments
- Efficiency meets excellence in customer care.
- Quality products, fair prices.
- Quality You Can Count On
The Team Brood “Crawler Brushed” Capacitor Bank is a great option for RC rock crawlers equipped with brushless motors. Designed with two 220uF 35V capacitors with low ESR and very high ripple current ratings, all while keeping a lower profile than other capacitor banks. Using this capacitor will help with stall currents when in a bind and improve startup by reducing the voltage ripple in the system.
NOTE:Â These should be installed as close to the battery terminals on the ESC as possible. If you can solder it directly to the post, even better.
Specifications:
Voltage Rating:Â 35v
Capacitance Rating:Â 440 uF
Low Frequency Rating:Â .903 Amps @ 120Hz per capacitor
High Frequency Rating:Â 1.29 Amps @ 100kHz per capacitor
ESR Rating:Â 38 mOhms per capacitor
Temperature Rating:Â 105 C
Wire Size:Â 4 Inches 14 AWG
Length:Â 13.50mm (NOT including Wire)
Width:Â 30mm (NOT including Wire)
Height:Â 15mm (NOT including Wire)
Weight:Â 13 Grams (Including Wire)
