Team Brood “Monster Truck Brushed” Capacitor Bank

The Team Brood “Crawler Brushless” Capacitor Bank is a great option for RC rock crawlers equipped with brushless motors. Designed with two 330uF 35V capacitors with low ESR and very high ripple current ratings, all while keeping a lower profile than other capacitor banks. Using this capacitor will help with the initial surge off the line by preventing the voltage from sagging as you accelerate.

NOTE: These should be installed as close to the battery terminals on the ESC as possible. If you can solder it directly to the post, even better.

Specifications:
Capacitance Rating: 660 uF
Voltage Rating: 35v
Low Frequency Rating: 1.253 Amps @ 120Hz per capacitor
High Frequency Rating: 1.79 Amps @ 100kHz per capacitor
ESR Rating: 26 mOhms per capacitor
Temperature Rating: 105 C
Wire Size: 4 Inches 14 AWG
Length: 13.50mm (NOT including Wire)
Width: 30mm (NOT including Wire)
Height: 17.50mm (NOT including Wire)
Weight: 14.50 Grams (Including Wire)
